Feature
UV light curing adhesive reacts after being exposed to UV light and has the advantages of fast speed, toughness and high strength. UV illumination is related to parameters such as the output intensity of the light source, the design of the reflector, and the distance of the irradiated object. Generally speaking, UV exposure = UV intensity x exposure time. The UV illumination energy is inversely proportional to the usage time of the lamp/light source.
Specification
．for Electronic/Optoelectronic Industry
| Appearance |
Item no. | Viscosity (cps) | Materials | Curing condition | Hardness | Shear strength | Temp. resistance |
| clear liquid | CM-3301 | 1900~2900 | PC/ABS | 1500 | D56 | 176.28 | -20~100℃ |
| clear liquid | CM-3302 | 5600~8400 | PVC/PVC | 1500 | D66 | - | -20~80℃ |
| light yellow liquid | CM-4401 | 2500~4100 | glass/plastic | 1500 | D50 | 33.87 | -20~80℃ |
| clear gel | CM-6601 | 4800~7200 | metal/plastic | 1500 | D53 | 80.63 | -20~100℃ |
* After high and low temperature cycle tests, there will be no debonding and cracking.
* Wire/jumper fixation, fast hardening, moisture and heat resistant.
* Fast packaging, low stress, high ion purity, suitable for PCB, FPC and other packaging.
* Suitable for PCB, PCA assembly, various switches, speakers, radars, LCD Panel sealing, mobile phones, optical fibers, digital cameras, LED lights and other packaging or coating applications.
．for Medical equipment and pipe industry
| Appearance |
Item no. | Viscosity (cps) | Materials | Curing condition | Hardness | Temp. resistance |
| light yellow liquid | CM-3303 | < 150 | PVC/PVC | 1500 | D80 | -20~80℃ |
| light yellow liquid | CM-3304 | 5600~8400 | PVC/PVC | 1500 | D66 | -20~80℃ |
| light yellow liquid | CM-3305 | 220~380 | PVC/PVC | 1500 | D40 | -20~80℃ |
* It is flexible, has high elongation, and complies with SGS and RoHS standards.
．for Glass to glass or metal bonding industry
| Appearance |
Item no. | Viscosity (cps) | Materials | Curing condition | Hardness | Shear strength | Temp. resistance |
| clear liquid | CM-4402 | 300~460 | glass/aluminum/stainless steel | 1500 | D51 | 164.03 | -20~110℃ |
| clear liquid | CM-4403 | 800~1300 | glass/aluminum/stainless steel | 1500 | D64 | 202.98 | -20~110℃ |
| clear liquid | CM-4404 | 1600~3200 | glass/aluminum | 1500 | D71 | HB | -30~120℃ |
* Passed rigorous high and low temperature change and long-term 25℃ water immersion tests.
* It will not come off after long-term exposure to the sun and rain, has excellent transparency, and will not turn yellow after aging test.
* Suitable for glass furniture, handicrafts, kitchen and bathroom supplies industries.
．UV Hard Coat
| Appearance |
Item no. | Viscosity | Materials | Curing condition | Temp. resistance | Package |
| yellow clear liquid | 7001A | Ford cup #4 | PC/ABS | 800 | 120℃/1h | 15kgs |
| yellow clear liquid | 7001B | Ford cup #4 | BMC/PBT/Nylon | 1500 | 200℃/1h | 15kgs |
* It is used in the structural forming of optical films, primers for car lights, hardening coatings for PC lampshades, casings for 3C products, UV water-based adhesive protective films for touch panels, etc.
* Contact us for more information.
．Usages
Electronics
Biotechnology
Materials and Chemicals
UV Curing Tech.
