Brief
In the automated application of hot melt adhesive, hot melt adhesive coating equipment is indispensable. HES hot melt adhesive machine has stable and rapid adhesive output and uniform adhesive quantity. It can be applied in dots, strips, spirals or with a scraper spray gun as required. Combined with complete product application consultation and after-sales service, HES glue machine has provided the best products for the automotive industry, packaging industry, filter industry, lamination industry, electronics industry, furniture industry, book binding industry and other industries.
Feature
| Item |
HS 0753 | HS 1104 | HS 110C2 | |
| Type | Pressure-holding type | Air pressure pump type | Heat pump type | |
| Glue tank capacity (liter) | 1 | 5 | 10 | |
| Max. melting speed (kg/hr) | 2.5 | 7 | 10 | |
| Max. working temp. (℃) | 220 | 200 | 200 | |
| Viscosity (cps) | 40000 | 12000 | 30000 | |
| Tube/nozzle | 1 | 1~2 | 1~2 | |
| Air pressure range (Kg/cm2) | 4 | 0.5~4 | — | |
| Dimension (LxWxH) mm | 390×350×610 | 560×330×480 | 700×430×470 | |
| Weight (kg) | 16 | 31 | 65 | |
| Tank heat up power (W) | 1100 | 3500 | 3000 | |
| Voltage | AC220V，50/60Hz | AC220V，50/60Hz | AC220V，50/60Hz | |
| Currency (A) | 5 | 16 | 22 | |
| Feature | * Pressure-holding system, stable glue supply * Safety buckle design, easy handle & operation * Glue applied in dot or strip type * Glue output is adjustable * Glue can be dispensed manually or automatically | * Easy glue adding * Can be used with various packaging machinery for precise control * Glue tank and nozzle are independently temp. controlled * Insulated hose has low heat loss and good thermal insulation * Double hoses, fixed or portable | * Alarm warning * Stable glue output, time-saving and convenient maintenance * Electronic frequency converter, precision flow control switch * Glue tank, nozzle and insulation hose are independently controlled and fully digitally displayed * Shift power on/off function according to actual needs |
* The above are the specifications of the standard model. There are other models for customers to choose from. Welcome to contact us.
