Brief
The most user-friendly platform laser engraving machine, with the choice of high stable output power Nd:YVO4 or Fiber laser source, combined with precision DC servo motor drive control, can engrave the best effect for you, whether it is graphics, logo on metal surface, or text, logo on plastic surface... StellarMark S290LS is the most professional model, through the user-friendly simple operation interface, you can also become a laser master.
Feature
● Pass-through doors: movable front and rear doors design, when the work object is too long or too large, it can pass directly through.
● User-friendly operation interface, even complex tasks can be easily completed, greatly improving work efficiency.
● Drag & Engrave: laser lens can be directly dragged, without the complicated setting steps of the engraving position.
● Smart LID™ innovative full cover design, convenient for machine maintenance.
● DC servo motor uses high-performance DC servo motor to provide precise, fast and reliable moving system.
● Power compensation: APC-automatic power compensation function, the power supply is more stable, ensuring high-quality laser output.
Specification
| Model | S290 LS |
| Work Area | 640 x 460 mm (extendable to 736 x 460 mm) |
| Max. Part Size (All doors closed) | 570 x 800 x 165 mm (LxWxH) |
| Max. Part Size (All doors open) | infinite x 800 x 165 mm (LxWxH) |
| Platform Size | 790 x 530 mm |
| Dimensions (W x D x H) | 1125 x 720 x 1005 mm |
| Laser Source | Nd: YVO4 10W or Fiber 20W / 40W |
| Cooling | Air Cool |
| Drive | Closed-loop DC Servo Control |
| Speed Control | Adjustable from 0.1~100% |
| Max. Speed | YVO4: 60 IPS ; Fiber: 80 IPS* |
| Distance Accuracy | 0.254mm or 0.1% of move, whichever is greater |
| Operating Environment | Temp.: 15℃ ~ 35℃ ; Humidity: 10~80% |
| Z-Axis Movement | Automatic |
| Resolution | 125~1000 DPI |
| Display Panel | 4-line LCD panel showing current file name, total working time, laser power, engraving speed… |
| Interface | Standard printer or USB 2.0 port |
| Memory | Standard 32MB (extendable to 64MB) |
| Safety | Class IIIR Laser Product Compliant with CDRH 2006/42/EC Machine Directive Compliance |
| Operating Voltage | AC 100~220 V Auto switching |
| Power Consumption | YVO4: 2,200W ; Fiber: 1,320W |
| Fume Extraction System | External exhaust system (4" exhaust port) |
* The maximum speed does not equal the maximum output. Please contact sales personnel for more information.
* The above specifications are subject to change without prior notice.
